Maximum width of material: |
1200-2400mm (width optional) |
|
Maximum diameter of unwinding: |
Φ800mm |
|
Maximum diameter of winding: |
Φ800mm |
|
Minimum effective width of slitting: |
100mm (Min) |
|
Slitting speed: |
300m/min |
|
Unwinding and loading form: |
3" key type air shaft |
|
Rewinding and loading form: |
3" slip type air shaft |
|
Applicable materials: |
12-40um PE film 12～40μm |
FTQL model slitter adopts servo motor winding control system. The unwinding tension adopts automatic detection and closed-loop automatic control. The equipment has meter counting shutdown function and diameter calculation shutdown function. Unwinding is equipped with a waste edge treatment device which is equipped with a non shaft air top clamping device and adopts a negative pressure high-speed edge suction mode.The slitter is used for cutting breathable film and non-breathable film (sanitary napkin,baby diaper bottom back sheet film etc.
